LTC7545ALG#TRPBF
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT A-OUT 20SSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet LTC7545ALG#TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$6.195
- 1,000$6.05526
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:1µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:5V, 14.25V ~ 15.75V
- Voltage - Supply, Digital:5V, 14.25V ~ 15.75V
- INL/DNL (LSB):±0.5 (Max), ±0.5 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:20-SSOP
- Mounting Type:Surface Mount
