MAX515EPA+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 10BIT V-OUT 8DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 1,939
Can ship immediately
Pricing:
- 1$6.487
- 100$5.6993
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:10
- Number of D/A Converters:1
- Settling Time:25µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±0.5 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:8-DIP (0.300", 7.62mm)
- Supplier Device Package:8-PDIP
- Mounting Type:Through Hole
