MAX507ACWG+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 24SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX507ACWG+T Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
- 1$14.248
- 1,000$12.064
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:5µs
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:±11.4V ~ 15.75V
- Voltage - Supply, Digital:11.4V ~ 15.75V
- INL/DNL (LSB):±0.75 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:24-SOIC
- Mounting Type:Surface Mount
