DAC8814IBDBTG4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT A-OUT 28SSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
-
ECAD Model
- Share
In Stock: 120
Can ship immediately
Pricing:
- 1$27.11412
- 250$26.87684
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:4
- Settling Time:500ns (Typ)
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:2.7V ~ 5.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±4 (Max), ±1.5 (Max)
- Architecture:Multiplying DAC
- Operating Temperature:-40°C ~ 85°C
- Package / Case:28-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:28-SSOP
- Mounting Type:Surface Mount
