MX7534JCWP+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 14BIT A-OUT 20SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MX7534JCWP+ Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$25.57111
- 36$21.6438
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:14
- Number of D/A Converters:1
- Settling Time:1.5µs
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:11.4V ~ 15.75V
- Voltage - Supply, Digital:11.4V ~ 15.75V
- INL/DNL (LSB):±2 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:20-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:20-SOIC
- Mounting Type:Surface Mount
