AD9136BCPZRL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 16BIT A-OUT 88LFCSP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD9136BCPZRL Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$85.974
- 2,000$78.34623
Quote It
Technical Details
- Series:TxDAC+®
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Bits:16
- Number of D/A Converters:2
- Settling Time:20ns (Typ)
- Output Type:Current - Unbuffered
- Differential Output:Yes
- Data Interface:JESD204B
- Reference Type:Internal
- Voltage - Supply, Analog:3.13V ~ 3.47V
- Voltage - Supply, Digital:1.14V ~ 1.26V
- INL/DNL (LSB):±2, ±1
- Architecture:Current Source
- Operating Temperature:-40°C ~ 85°C
- Package / Case:88-VFQFN Exposed Pad, CSP
- Supplier Device Package:88-LFCSP-VQ (12x12)
- Mounting Type:Surface Mount
