MAX5544ESA
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 14BIT V-OUT 8SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX5544ESA Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Bits:14
- Number of D/A Converters:1
- Settling Time:1µs (Typ)
- Output Type:Voltage - Unbuffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±4, ±0.5
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
- Mounting Type:Surface Mount
