AD5530BRUZ-REEL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 16TSSOP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD5530BRUZ-REEL Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:1
- Settling Time:20µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI, DSP
- Reference Type:External
- Voltage - Supply, Analog:±12V, ±15V
- Voltage - Supply, Digital:-
- INL/DNL (LSB):±1 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
- Mounting Type:Surface Mount
