AD7396AR-REEL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 12BIT V-OUT 24SOIC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD7396AR-REEL Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:2
- Settling Time:70µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:External
- Voltage - Supply, Analog:2.7V ~ 5.5V
- Voltage - Supply, Digital:2.7V ~ 5.5V
- INL/DNL (LSB):±2 (Max), ±1 (Max)
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:24-SOIC
- Mounting Type:Surface Mount
