SFW22R-2STAE1LF
Storage & Server IO (Amphenol ICC)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC TOP 22POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet SFW22R-2STAE1LF Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$0.38063
- 4,000$0.36405
Quote It
Technical Details
- Series:SFW-R
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top
- Number of Positions:22
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.33mm
- Height Above Board:0.106" (2.70mm)
- Locking Feature:Slide Lock
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Housing Material:Polyphenylene Sulfide (PPS), Glass Filled
- Actuator Material:Polyphenylene Sulfide (PPS), Glass Filled
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:100V
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
