0526100772
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- Description1.0 FPC ZIF SMT HSG ASSY 7CKT EM
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.3962
Quote It
Technical Details
- Series:Easy-On 52610
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:7
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.226" (5.74mm)
- Locking Feature:Slide Lock
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Housing Material:Polyamide (PA46), Nylon 4/6, Glass Filled
- Actuator Material:Polyphenylene Sulfide (PPS), Glass Filled
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:125V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
