AYF332735
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC 27POS 0.30MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet AYF332735 Datasheet
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$0.6783
- 5,000$0.6783
Quote It
Technical Details
- Series:Y3B
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top and Bottom
- Number of Positions:27
- Pitch:0.012" (0.30mm)
- Termination:Solder
- FFC, FCB Thickness:0.20mm
- Height Above Board:0.035" (0.88mm)
- Locking Feature:Flip Lock, Backlock
- Cable End Type:Tapered
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP)
- Actuator Material:Liquid Crystal Polymer (LCP)
- Features:-
- Voltage Rating:50V
- Operating Temperature:-55°C ~ 85°C
- Material Flammability Rating:UL94 V-0
