006200514230000+
KYOCERA Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC BOTTOM 14POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$0.8004
- 1,000$0.784
Quote It
Technical Details
- Series:6200, Kyocera
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:14
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.114" (2.90mm)
- Locking Feature:Slide Lock
- Cable End Type:Straight
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Plastic
- Actuator Material:-
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-20°C ~ 85°C
- Material Flammability Rating:-
