487576-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC VERT 9POS 1.27MM PCB
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 487576-1 Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
- 1$1.07743
- 12,000$1.04074
Quote It
Technical Details
- Series:AMPMODU
- Package:Tube
- Part Status:Active
- Flat Flex Type:FFC
- Mounting Type:Through Hole
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:9
- Pitch:0.050" (1.27mm)
- Termination:Solder
- FFC, FCB Thickness:0.10mm ~ 0.31mm
- Height Above Board:0.310" (7.87mm)
- Locking Feature:Slide Lock
- Cable End Type:Straight
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Thermoplastic
- Actuator Material:Thermoplastic
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:150V
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:-
