FH12F-40S-0.5SH(55)
Hirose- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC BOTTOM 40POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$1.47
- 2,000$1.47
Quote It
Technical Details
- Series:FH12
- Package:Tape & Reel (TR)
- Part Status:Last Time Buy
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:40
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.18mm
- Height Above Board:0.079" (2.00mm)
- Locking Feature:Flip Lock
- Cable End Type:Straight
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Housing Material:Polyamide (PA), Nylon
- Actuator Material:Polyphenylene Sulfide (PPS)
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
