0513742073
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC VERT 20POS 0.50MM SMD
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 0513742073 Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$2.93468
- 2,000$2.93468
Quote It
Technical Details
- Series:Easy-On 51374
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:20
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.159" (4.04mm)
- Locking Feature:Flip Lock
- Cable End Type:Straight, Tapered
- Contact Material:Copper Alloy
- Contact Finish:Tin Bismuth
- Housing Material:Liquid Crystal Polymer (LCP), Glass Filled
- Actuator Material:Polyphenylene Sulfide (PPS), Glass Filled
- Features:Solder Retention, Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-25°C ~ 85°C
- Material Flammability Rating:UL94 V-0
