FH41-40S-0.5SH(99)
Hirose
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC BOTTOM 40POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet FH41-40S-0.5SH(99) Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
- 1$3.4
- 500$3.23
Quote It
Technical Details
- Series:FH41
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FFC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:40
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.098" (2.50mm)
- Locking Feature:Flip Lock, Backlock
- Cable End Type:Tabbed
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP), Halogen Free
- Actuator Material:Liquid Crystal Polymer (LCP), Halogen Free
- Features:Solder Retention
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 105°C
- Material Flammability Rating:UL94 V-0
