0522711890
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC BOTTOM 18POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:52271
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:18
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.118" (3.00mm)
- Locking Feature:Slide Lock
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin-Lead
- Housing Material:Polyamide (PA46), Nylon 4/6
- Actuator Material:Polyphenylene Sulfide (PPS)
- Features:Solder Retention, Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
