0039513304
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC VERT 30POS 1.25MM PCB
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:5597
- Package:Tray
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Through Hole
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:30
- Pitch:0.049" (1.25mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.386" (9.80mm)
- Locking Feature:Slide Lock
- Cable End Type:Straight
- Contact Material:Phosphor Bronze
- Contact Finish:Tin-Lead
- Housing Material:Polybutylene Terephthalate (PBT), Polyester
- Actuator Material:Polybutylene Terephthalate (PBT), Polyester
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:200V
- Operating Temperature:-20°C ~ 80°C
- Material Flammability Rating:UL94 V-0
