0905003020
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC VERT 20POS 2.54MM PCB
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:90500
- Package:Tube
- Part Status:Obsolete
- Flat Flex Type:FFC
- Mounting Type:Through Hole
- Connector/Contact Type:Contacts, Vertical - 2 Sided
- Number of Positions:20
- Pitch:0.100" (2.54mm)
- Termination:Solder
- FFC, FCB Thickness:0.20mm
- Height Above Board:0.346" (8.80mm)
- Locking Feature:Slide Lock
- Cable End Type:Notched
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polybutylene Terephthalate (PBT), Glass Filled
- Actuator Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:250V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
