FH21-5S-1DS
Hirose- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC FPC 5POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet FH21-5S-1DS Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:FH21
- Package:Bulk
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Through Hole, Right Angle
- Connector/Contact Type:Contacts, Top and Bottom
- Number of Positions:5
- Pitch:0.039" (1.00mm)
- Termination:Kinked Pin
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.106" (2.70mm)
- Locking Feature:-
- Cable End Type:Straight
- Contact Material:Phosphor Bronze
- Contact Finish:Solder Plating
- Housing Material:Polybutylene Terephthalate (PBT)
- Actuator Material:-
- Features:Low Insertion Force (LIF)
- Voltage Rating:50V
- Operating Temperature:-30°C ~ 70°C
- Material Flammability Rating:UL94 V-0
