10013057-211200ELF
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC BOTTOM 21POS 0.30MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 10013057-211200ELF Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SFYL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Flat Flex Type:FFC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:21
- Pitch:0.012" (0.30mm)
- Termination:Solder
- FFC, FCB Thickness:0.20mm
- Height Above Board:0.047" (1.20mm)
- Locking Feature:Flip Lock
- Cable End Type:Notched
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Thermoplastic, Glass Filled
- Actuator Material:Plastic
- Features:Low Insertion Force (LIF)
- Voltage Rating:200V
- Operating Temperature:-25°C ~ 85°C
- Material Flammability Rating:UL94 V-0
