HFW27S-2STE1LF
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC FPC VERT 27POS 1MM SMD
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet HFW27S-2STE1LF Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.54
- 1,000$0.27192
- 2,000$0.26368
- 3,000$0.2472
- 5,000$0.23896
- 10,000$0.22248
- 25,000$0.21424
Quote It
Technical Details
- Series:HFW
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:27
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm, 0.33mm
- Height Above Board:0.209" (5.30mm)
- Locking Feature:-
- Cable End Type:Straight, Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polyamide (PA6T), Nylon 6T, Glass Filled
- Actuator Material:-
- Features:-
- Voltage Rating:100V
- Operating Temperature:-55°C ~ 85°C
- Material Flammability Rating:UL94 V-0
