5-520415-4
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC VERT 4POS 2.54MM PCB
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 5-520415-4 Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Triomate
- Package:Bulk
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Through Hole
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:4
- Pitch:0.100" (2.54mm)
- Termination:Solder
- FFC, FCB Thickness:0.13mm ~ 0.38mm
- Height Above Board:0.273" (6.93mm)
- Locking Feature:-
- Cable End Type:-
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polyester Thermoplastic, Glass Filled
- Actuator Material:-
- Features:-
- Voltage Rating:250V
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
