SFW26S-2STE1
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC FPC VERT 26POS 1MM SMD
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet SFW26S-2STE1 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SFW
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount
- Connector/Contact Type:Contacts, Vertical - 1 Sided
- Number of Positions:26
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm, 0.33mm
- Height Above Board:0.209" (5.30mm)
- Locking Feature:Slide Lock
- Cable End Type:Straight, Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin Alloy
- Housing Material:Thermoplastic, Glass Filled
- Actuator Material:Thermoplastic, Glass Filled
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:100V
- Operating Temperature:-55°C ~ 85°C
- Material Flammability Rating:UL94 V-0
