HFW13R-2STE1LF
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FFC FPC TOP 13POS 1MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet HFW13R-2STE1LF Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HFW-R
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top
- Number of Positions:13
- Pitch:0.039" (1.00mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.075" (1.90mm)
- Locking Feature:-
- Cable End Type:Straight or Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polyamide (PA6T), Nylon 6T, Glass Filled
- Actuator Material:-
- Features:-
- Voltage Rating:100V
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
