HLW11R-6C7LF
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN CIC TOP 11POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet HLW11R-6C7LF Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HLW-R
- Package:Tray
- Part Status:Obsolete
- Flat Flex Type:CIC
- Mounting Type:Through Hole, Right Angle
- Connector/Contact Type:Contacts, Top
- Number of Positions:11
- Pitch:0.039" (1.00mm)
- Termination:Kinked Pin
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.154" (3.90mm)
- Locking Feature:-
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polybutylene Terephthalate (PBT), Glass Filled
- Actuator Material:-
- Features:-
- Voltage Rating:100V
- Operating Temperature:-55°C ~ 85°C
- Material Flammability Rating:UL94 V-0
