0520430819
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC BOTTOM 8POS 1.00MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 0520430819 Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:52043
- Package:Tray
- Part Status:Obsolete
- Flat Flex Type:FPC
- Mounting Type:Through Hole, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:8
- Pitch:0.039" (1.00mm)
- Termination:Kinked Pin
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.165" (4.20mm)
- Locking Feature:Slide Lock
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin Bismuth
- Housing Material:Polyamide (PA66), Nylon 6/6
- Actuator Material:Polyester
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-20°C ~ 80°C
- Material Flammability Rating:UL94 V-0
