SFV7R-3STE1HLF
Storage & Server IO (Amphenol ICC)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC BOTTOM 7POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet SFV7R-3STE1HLF Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SFV-R
- Package:Tape & Reel (TR)
- Part Status:Active
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:7
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm, 0.33mm
- Height Above Board:0.071" (1.80mm)
- Locking Feature:Slide Lock
- Cable End Type:Notched
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polyamide (PA), Nylon, Glass Filled, Halogen Free
- Actuator Material:Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
