5034802040
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- Description05 FPC BF H=10 ASSY
- CategoryFFC, FPC (Flat Flexible) Connectors
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:BackFlip, Easy-On 503480 FHB1
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Flat Flex Type:FFC, FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top and Bottom
- Number of Positions:20
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.039" (1.00mm)
- Locking Feature:Flip Lock, Backlock
- Cable End Type:Straight or Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP), Glass Filled
- Actuator Material:Polyamide (PA), Nylon, Glass Filled
- Features:Solder Retention
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
