09300160295
HARTING- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN BASE SIDE ENTRY SZ16B PG21
- CategoryHeavy Duty Connectors - Housings, Hoods, Bases
- Datasheet 09300160295 Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$63.87
Quote It
Technical Details
- Series:Han® B
- Package:Bulk
- Part Status:Active
- Connector Type:Base - Box Mount
- Style:Side Entry
- Size:16B
- Lock Location:Locking Clip (1) on Base Bottom
- Thread Size:PG21
- Size / Dimension:4.606" L x 2.244" W x 3.181" H (117.00mm x 57.00mm x 80.80mm)
- Housing Color:Gray
- Features:Cover, Feed Through
- Ingress Protection:IP65 - Dust Tight, Water Resistant
- Housing Material:Aluminum, Die Cast
- Housing Finish:Powder Coated
- Operating Temperature:-40°C ~ 125°C
