M2022TYW01-JB
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH ROCKER DPDT 6A 125V
- CategoryRocker Switches
- Datasheet M2022TYW01-JB Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$7.55
Quote It
Technical Details
- Series:M
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount, Flange
- Circuit:DPDT
- Switch Function:On-On
- Current Rating (Amps):6A (AC), 4A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Concave (Standard V)
- Color - Actuator/Cap:White
- Actuator Marking:No Marking
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Solder Lug
- Ingress Protection:-
- Features:Epoxy Sealed Terminals
- Panel Cutout Dimensions:Rectangular - 28.50mm x 16.00mm
- Operating Temperature:-30°C ~ 85°C
