JWL11RAA
NKK Switches
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH ROCKER SPST 16A 125V
- CategoryRocker Switches
- Datasheet JWL11RAA Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$7.56
Quote It
Technical Details
- Series:JW
- Package:Bulk
- Part Status:Active
- Mounting Type:Panel Mount, Snap-In
- Circuit:SPST
- Switch Function:On-Off
- Current Rating (Amps):16A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Concave (Curved)
- Color - Actuator/Cap:Black
- Actuator Marking:No Marking
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Solder, Quick Connect - 0.187" (4.7mm)
- Ingress Protection:Dust Proof
- Features:Epoxy Sealed Terminals
- Panel Cutout Dimensions:Rectangular - 29.50mm x 20.50mm
- Operating Temperature:-25°C ~ 70°C
