JWM21BH1H-H
NKK Switches- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH ROCKER DPST 10A 125V
- CategoryRocker Switches
- Datasheet JWM21BH1H-H Datasheet
-
ECAD Model
- Share
In Stock: 127
Can ship immediately
Pricing:
- 1$9.91
Quote It
Technical Details
- Series:JW
- Package:Tray
- Part Status:Active
- Mounting Type:Panel Mount, Snap-In
- Circuit:DPST
- Switch Function:On-Off
- Current Rating (Amps):10A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Concave (Curved)
- Color - Actuator/Cap:Gray
- Actuator Marking:O I
- Illumination Type, Color:-
- Illumination Voltage (Nominal):-
- Termination Style:Solder, Quick Connect - 0.110" (2.8mm)
- Ingress Protection:Dust Proof
- Features:Epoxy Sealed Terminals
- Panel Cutout Dimensions:Rectangular - 24.00mm x 15.40mm
- Operating Temperature:-25°C ~ 70°C
