TRG10R240-01E03 VI

Cincon
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionAC/DC WALL MNT ADAPTER 24V 9.6W
  • CategoryAC DC Desktop, Wall Adapters
  • ECAD Model
  • Share
In Stock: 138

Can ship immediately

Pricing:
  • 1$11.9692
  • 50$11.8508

Quote It

Technical Details

  • Series:TRG10R (10W)
  • Package:Box
  • Part Status:Active
  • Region Utilized:International
  • Form:Wall Mount (Class II)
  • Input Type:Multi-Blade (Sold Separately)
  • Voltage - Input:90 ~ 264 VAC
  • Voltage - Output:24V
  • Current - Output (Max):400mA
  • Power (Watts):9.6 W
  • No Load Power Consumption:75mW (Max)



  • Polarization:Positive Center
  • Applications:ITE (Commercial)
  • Efficiency:Level VI, CoC Tier 2
  • Operating Temperature:-20°C ~ 60°C
  • Output Connector:Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm
  • Cord Length:70.9" (1.80m)
  • Input Connector:Multi-Blade (Sold Separately)
  • Size / Dimension:2.86" L x 1.40" W x 1.82" H (72.6mm x 35.6mm x 46.3mm)
  • Approval Agency:CE, cULus, FCC, GS, PSE, TUV
  • Standard Number:-
