GST40A24-P1M
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAC/DC DESKTOP ADAPTER 24V 40W
- CategoryAC DC Desktop, Wall Adapters
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$20.6
Quote It
Technical Details
- Series:GST40A (40W)
- Package:Box
- Part Status:Active
- Region Utilized:International
- Form:Desktop (Class I)
- Input Type:Cord (Sold Separately)
- Voltage - Input:90 ~ 264 VAC
- Voltage - Output:24V
- Current - Output (Max):1.67A
- Power (Watts):40 W
- No Load Power Consumption:75mW (Max)
- Polarization:Positive Center
- Applications:ITE (Commercial)
- Efficiency:Level VI
- Operating Temperature:-30°C ~ 70°C
- Output Connector:Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm
- Cord Length:70.9" (1.80m)
- Input Connector:IEC 320-C14
- Size / Dimension:4.92" L x 1.97" W x 1.24" H (125.0mm x 50.0mm x 31.5mm)
- Approval Agency:BIS, BSMI, CB, CCC, CE, cULus, EAC, GS, KC, PSE, RCM, SIRIM
- Standard Number:-
