PSA60R-240-R

Technical Details

• Series:PSA60R (60W)
• Package:Box
• Part Status:Active
• Region Utilized:International
• Form:Wall Mount (Class II)
• Input Type:Multi-Blade (Sold Separately)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:24V
• Current - Output (Max):2.5A
• Power (Watts):60 W
• No Load Power Consumption:300mW (Max)

• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level V
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 10.0mm
• Cord Length:59" (1.50m)
• Input Connector:Multi-Blade
• Size / Dimension:4.06" L x 2.59" W x 1.57" H (103.0mm x 66.0mm x 39.9mm)
• Approval Agency:CE, cULus
• Standard Number:-
