EPS240063UH-P5P-SZ

Technical Details

• Series:EPS (15W)
• Package:Box
• Part Status:Obsolete
• Region Utilized:North America
• Form:Wall Mount (Class II)
• Input Type:Fixed Blade
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:24V
• Current - Output (Max):630mA
• Power (Watts):15 W
• No Load Power Consumption:300mW (Max)

• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level IV
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 12.0mm
• Cord Length:72" (1.83m)
• Input Connector:NEMA 1-15P
• Size / Dimension:2.83" L x 1.38" W x 1.87" H (72.0mm x 35.0mm x 47.6mm)
• Approval Agency:-
• Standard Number:-
