SN74AHCT00DBR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14SSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 4,066
Can ship immediately
Pricing:
- 1$0.41
- 2,000$0.1089
- 6,000$0.1023
- 10,000$0.0957
Quote It
Technical Details
- Series:74AHCT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:7.9ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SSOP
- Package / Case:14-SSOP (0.209", 5.30mm Width)
