MC74HCT14AFEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE XNOR 4CH 2-INP SOEIAJ
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 27,885
Can ship immediately
Pricing:
- 1$0.14
Quote It
Technical Details
- Series:74HCT
- Package:Bulk
- Part Status:Active
- Logic Type:XNOR (Exclusive NOR)
- Number of Circuits:4
- Number of Inputs:2
- Features:Schmitt Trigger
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:4mA, 4mA
- Logic Level - Low:0.5V ~ 0.6V
- Logic Level - High:1.9V ~ 2.1V
- Max Propagation Delay @ V, Max CL:32ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SOEIAJ-14
- Package / Case:14-SOIC (0.209", 5.30mm Width)
