74LVC02ADB,112
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionNOR GATE, LVC/LCX/Z SERIES, 4-FU
- CategoryLogic - Gates and Inverters
- Datasheet 74LVC02ADB,112 Datasheet
-
ECAD Model
- Share
In Stock: 8,295
Can ship immediately
Pricing:
- 1$0.14
- 1,092$0.14
Quote It
Technical Details
- Series:74LVC
- Package:Tube
- Part Status:Active
- Logic Type:NOR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:1.2V ~ 3.6V
- Current - Quiescent (Max):40 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.12V ~ 0.8V
- Logic Level - High:1.08V ~ 2V
- Max Propagation Delay @ V, Max CL:4.4ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SSOP
- Package / Case:14-SSOP (0.209", 5.30mm Width)
