DM74AS21N
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND 2CH 4-INP 14DIP
- CategoryLogic - Gates and Inverters
- Datasheet DM74AS21N Datasheet
-
ECAD Model
- Share
In Stock: 4,794
Can ship immediately
Pricing:
- 1$0.14
- 1,000$0.14
Quote It
Technical Details
- Series:74AS
- Package:Tube
- Part Status:Obsolete
- Logic Type:AND Gate
- Number of Circuits:2
- Number of Inputs:4
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:2mA, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:6ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Through Hole
- Supplier Device Package:14-PDIP
- Package / Case:14-DIP (0.300", 7.62mm)
