MC74HC14ADTR2

Technical Details

• Series:74HC
• Package:Bulk
• Part Status:Obsolete
• Logic Type:Inverter
• Number of Circuits:6
• Number of Inputs:6
• Features:Schmitt Trigger
• Voltage - Supply:2V ~ 6V
• Current - Quiescent (Max):1 µA

• Current - Output High, Low:5.2mA, 5.2mA
• Logic Level - Low:0.3V ~ 1.2V
• Logic Level - High:1.5V ~ 4.2V
• Max Propagation Delay @ V, Max CL:13ns @ 6V, 50pF
• Operating Temperature:-55°C ~ 125°C
• Mounting Type:Surface Mount
• Supplier Device Package:14-TSSOP
• Package / Case:14-TSSOP (0.173", 4.40mm Width)
