74LVX32SJX
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 4CH 2-INP 14SOP
- CategoryLogic - Gates and Inverters
- Datasheet 74LVX32SJX Datasheet
-
ECAD Model
- Share
In Stock: 14,107
Can ship immediately
Pricing:
- 1$0.18
Quote It
Technical Details
- Series:74LVX
- Package:Bulk
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:4mA, 4mA
- Logic Level - Low:0.5V ~ 0.8V
- Logic Level - High:1.5V ~ 2.4V
- Max Propagation Delay @ V, Max CL:10.1ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
