NC7NP04K8X
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERTER 3CH 3-INP US8
- CategoryLogic - Gates and Inverters
- Datasheet NC7NP04K8X Datasheet
-
ECAD Model
- Share
In Stock: 94,439
Can ship immediately
Pricing:
- 1$0.2
Quote It
Technical Details
- Series:7NP
- Package:Bulk
- Part Status:Obsolete
- Logic Type:Inverter
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:0.9V ~ 3.6V
- Current - Quiescent (Max):900 nA
- Current - Output High, Low:2.6mA, 2.6mA
- Logic Level - Low:0.7V ~ 0.9V
- Logic Level - High:1.6V ~ 2.1V
- Max Propagation Delay @ V, Max CL:9.2ns @ 3.3V, 30pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:US8
- Package / Case:8-VFSOP (0.091", 2.30mm Width)
