NLU3G14MUTAG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERT SCHMITT 3CH 3-IN 8UDFN
- CategoryLogic - Gates and Inverters
- Datasheet NLU3G14MUTAG Datasheet
-
ECAD Model
- Share
In Stock: 244,132
Can ship immediately
Pricing:
- 1$0.23
- 3,000$0.23
Quote It
Technical Details
- Series:MiniGate™
- Package:Bulk
- Part Status:Obsolete
- Logic Type:Inverter
- Number of Circuits:3
- Number of Inputs:3
- Features:Schmitt Trigger
- Voltage - Supply:1.65V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.2V ~ 3.85V
- Max Propagation Delay @ V, Max CL:10.6ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:8-UDFN (1.8x1.2)
- Package / Case:8-UFDFN
