MC74VHC08MELG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND 4CH 2-INP SOEIAJ-14
- CategoryLogic - Gates and Inverters
- Datasheet MC74VHC08MELG Datasheet
-
ECAD Model
- Share
In Stock: 50,006
Can ship immediately
Pricing:
- 1$0.24
Quote It
Technical Details
- Series:74VHC
- Package:Bulk
- Part Status:Obsolete
- Logic Type:AND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.5V
- Logic Level - High:1.5V
- Max Propagation Delay @ V, Max CL:7.9ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SOEIAJ-14
- Package / Case:14-SOIC (0.209", 5.30mm Width)
