74HCT02N,652
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NOR 4CH 2-INP 14DIP
- CategoryLogic - Gates and Inverters
- Datasheet 74HCT02N,652 Datasheet
-
ECAD Model
- Share
In Stock: 58,062
Can ship immediately
Pricing:
- 1$0.25
Quote It
Technical Details
- Series:74HCT
- Package:Tube
- Part Status:Obsolete
- Logic Type:NOR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:4mA, 4mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:19ns @ 4.5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Through Hole
- Supplier Device Package:14-DIP
- Package / Case:14-DIP (0.300", 7.62mm)
