MC74AC32NG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 4CH 2-INP 14DIP
- CategoryLogic - Gates and Inverters
- Datasheet MC74AC32NG Datasheet
-
ECAD Model
- Share
In Stock: 17,684
Can ship immediately
Pricing:
- 1$0.27
Quote It
Technical Details
- Series:74AC
- Package:Tube
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):4 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.1V ~ 3.85V
- Max Propagation Delay @ V, Max CL:7.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Through Hole
- Supplier Device Package:14-PDIP
- Package / Case:14-DIP (0.300", 7.62mm)
