74AC08SJX
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAND GATE, AC SERIES, 4 FUNC, 2-I
- CategoryLogic - Gates and Inverters
- Datasheet 74AC08SJX Datasheet
-
ECAD Model
- Share
In Stock: 36,581
Can ship immediately
Pricing:
- 1$0.28
- 2,000$0.28
Quote It
Technical Details
- Series:74AC
- Package:Bulk
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.1V ~ 3.85V
- Max Propagation Delay @ V, Max CL:7.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
